₨67,000.00
Max PV4200 3.5KW Hybrid Inverter
The Max PV4200 3.5kW Hybrid Inverter is a compact solar inverter suitable for residential use, integrating solar power, battery storage, and grid supply in a single unit. It features advanced MPPT technology for efficient solar energy harvesting and maintains high performance under varying conditions. With efficiency up to 96–97%, it delivers reliable energy conversion and uninterrupted backup during power outages. Its durable design with intelligent monitoring ensures long-term reliability and easy system management.
Specifications
- Model: Max PV4200 3.5 kW Hybrid Inverter
- Inverter Type: Hybrid (Solar + Battery + Grid)
- Rated Power: 3200 VA (~3.2 kW) / 3.5 kW class
- AC Input Voltage: 230 VAC
- Selectable AC Input Range: 170 – 280 VAC (PC), 90 – 280 VAC (Home)
- AC Output Frequency: 50 Hz / 60 Hz (auto sensing)
- AC Voltage Regulation: 230 VAC ± 5%
- Surge Power: 6000 VA
- Efficiency (Peak PV to Inverter): ~97%
- Efficiency (Peak Battery to Inverter): ~94%
- Transfer Time: ~10 ms (PC); ~20 ms (Home)
- Battery Voltage: 24 VDC
- Floating Charge Voltage: ~27 VDC
- Maximum AC Charger Current: ~60 A
- Maximum PV Array Power: 4200 W
- MPPT Operating Voltage Range: 120 – 430 VDC
- Maximum PV Open‑Circuit Voltage: ~500 VDC
- Maximum Charge Current (MPPT): ~100 A
- Maximum PV Input Current: ~18 A
- Communication: RS232 / GPRS / Wi‑Fi support
- Operating Temperature: 0 °C – 55 °C
- Storage Temperature: ‑15 °C – 60 °C
- Humidity: 5% – 95% (non‑condensing)
- Protection Level: IP21
- Dimensions: ~367 × 318 × 122.5 mm
- Weight: ~7.2 kg
Max PV4200 3.5kW Hybrid Inverter – Efficient & Versatile Solar Solution
The Max PV4200 3.5kW Hybrid Inverter is designed for residential and small commercial solar systems, combining solar power, battery storage, and grid supply in a single, compact unit. Engineered with advanced hybrid technology, it delivers high efficiency, stable performance, and reliable backup during power outages, making it ideal for users seeking energy independence and cost savings.
With a maximum efficiency of up to 97%, the inverter ensures optimal energy conversion with minimal losses. Its built-in MPPT technology allows maximum energy harvesting from solar panels, even in varying sunlight conditions, ensuring consistent power supply throughout the day. The inverter supports seamless integration with lithium-ion or lead-acid batteries, providing flexible energy storage solutions for uninterrupted electricity.
The Max PV4200 3.5kW Hybrid Inverter is fully compatible with net metering systems, making it suitable for households, offices, and small commercial setups that want to utilize solar energy efficiently while reducing electricity bills.
SUNSOLAR – Pakistan’s Trusted Solar Company
At SUNSOLAR, we offer 100% genuine Max inverters along with professional installation and tailored solar solutions. Our team ensures smooth system setup, from initial design to net metering approval, helping you achieve maximum energy efficiency and savings.
Why Buy from SUNSOLAR?
✅ 100% Original Max Products
✅ Expert Installation & System Design
✅ Net Metering Support
✅ Local Warranty & Technical Assistance
✅ Competitive Pricing with Premium Service
Order Now – Max PV4200 3.5kW Hybrid Inverter
Upgrade to a reliable and efficient solar solution with the Max PV4200 3.5kW Hybrid Inverter. Contact SUNSOLAR today and start harnessing clean, uninterrupted solar energy.
